CNC Cylindrical Grinding Machine - Angular
OPTIONAL SYSTEMS:
In-Process Gauge, Flagging Device, Automatic Wheel Balancing System, Gap & Crash Control System
Plunge Grinding
Face Grinding
Internal Grinding
Traverse Grinding
Specifications
| Centre Hnicht | mm | 150 | 200 / 250 |
| Swing Diameter | mm | 295 | 395 / 495 |
| Max. Grinding Length | mm | 300 / 500 / 600 / 800 | 1000 / 1250 / 1500 / 1700 |
| Grinding Wheel Dia. | mm | 350 / 400 | 400 / 500 |
| Grinding wheel width | mm | 40 / 50 | 40 / 50 / 63 |
| Rapid Approach | mm | 50 | 50 |
| Workhead centre | MT | 4 / 5 | 4 / 5 |
| Tailstock centre | MT | 3 / 4 | 4 / 5 |
The Engineering Behind Every Grind
Unmatched Accuracy
Micron-level tolerances made standard
Built for Performance
For both tool room finesse & production floor ruggedness
Designed to Last
Turcite slideways, hydrodynamic spindles, and frictionless bearings
Service-First Engineering
Designed with maintainability in mind
Download Brochures
“It’s Not Just a Machine. It’s a System.”
A closer look at the systems engineered for repeatability, longevity, and industry-defining accuracy.
Wheelhead Assembly - Bush or Cartridge Spindle
-
At the core of our cylindrical grinder lies a wheelhead built to adapt to your precision needs.
We offer two engineering-grade configurations:
-
White Metal Bush - Known for its silent glide and long-life consistency, this setup resists wear across years of load cycles. Ideal for high-volume reliability.
-
Cartridge Spindle Option - For operations demanding ultra-high tolerance and minimal runout, our cartridge spindle setup delivers performance that rivals new-generation CNC grinders.
-
Both options are hand-aligned and balanced in-house to deliver what matters most: unwavering accuracy cycle after cycle, year after year.
Machine Bed & Foundation Rigidity
-
Not just heavy. Engineered to be unshakeable.
-
Every MMW grinder is built on a bed cast from custom-formulated graded cast iron, developed specifically for MMW’s manufacturing platform. It’s not generic. It’s ours.
-
These castings are vibration-damped, stress-relieved, and structurally optimized to ensure stability under the harshest workshop conditions because precision begins where the machine meets the floor.
Scraping Alignment + Blue Matching
-
Old-school obsession meets modern-day tolerances.
-
Every Maruti grinder is hand-scraped and blue-matched by veterans with over 20 years of alignment experience.
-
No digital shortcut can replicate the feel of a perfectly mated surface one that’s been hand-aligned to ensure micron-level flatness and zero backlash.
Lubrication Architecture – Fully Automatic
-
Maintenance should never interrupt momentum. That’s why every MMW’s cylindrical grinder comes equipped with an automatic lubrication system. From spindle bushings to slideways, lubrication is delivered precisely where it’s needed, when it’s needed extending component life and keeping friction out of your workflow.
Not Just Engineered. Designed to Be Noticed.
-
We believe performance isn’t just measured in tolerances it's also felt in presence.
-
That’s why every Maruti machine is finished using a 3-layer industrial painting process, designed not just for protection, but for aesthetic dominance. Because a machine that performs like this should look like it belongs in a world-class workshop not blend into the background.
